Brand Name : KAEMI or GM(Self-owned Brand)
Model Number : GM-1209P6
Certification : CE,CCC,ISO9001,etc
Place of Origin : China
MOQ : 1set
Price : USD2499-2999/Set
Payment Terms : T/T,Trade Assurance Order on Alibaba(All Payment method Supported on Alibaba Available)
Supply Ability : 500 Sets Per Month
Delivery Time : 3-7 Working Days
Packaging Details : Professional Wooden Case for Import and Export(with Official Chop)--1209P6-1 Set Wooden Case Package Dimension:176*163*60cm(For Cutter), add 41*42*42cm(1500w Air Pump), Total Gross Weight:235Kg, Total Volume:2.7 CBM(For Reference, Real Figure more or less
Condition : New
Materials : Aluminium Allloy and Stainless Steel
Function : Paper Pattern Printing and Cutting
Printing Head : Dual Head HP45 Ink Cartridges Type
Printing Speed : About 90 Square Meters Per Hour
Cutting Speed : Maximum 1200mm/s
Connection Method : Cable Direct Connection, Both USB or LAN Cable
Cutting Materials : Kraft White Paper Thin PVC Sheet, Sticker, Rubber, etc
Application Areas : Garment, Shoes, Bags, Furniture, Advertising, etc
Working Scope : 9060/1209/1509/1510/1512,etc can be customized
Maximum Paper Cutting : Maximum 2-3mm Thickness
Software : Independent Cutter Software, Compatible with All CAD Editing Softwares
Warranty : 1 Year for Whole Machines, Lifetime Maintenance Service
Term of Delivery : Exw, FCA, CNF, CIF, FOB, DDP All Support
Company Features : Listed Brand in CCTV, High Tech Enterprise in China
Aftersales : 5-6 Person Aftersales Team, 24 Hours Onlines Service
Distributors or Agents : 50+ Agents or Distributors All Over the World
Main Features:
1. Unique Inkjet and Cutting Double Track Tracking System
2. Unique Paper Card Abnormal Monitoring System
3. Cutting Starting Points and Cutting Sequence Display System
4. Automatic Paging System
5. Fault Detection System for Whole Machine
Model | GM-1209P5 | GM-1509P5 | GM-1510P5 | GM-1512P5 |
Cutting Window(Fabric Scope) | 1200*900mm | 1500*900mm | 1500*1000mm | 1500*1200mm |
Overall Dimension(mm) | 1700*1570*1100 | 2000*1570*1100 | 2000*1570*1100 | 2000*1770*1100 |
Max Speed | 1200mm/s | 1200mm/s | 1200mm/s | 1200mm/s |
Materials Fasten | Vacuum Adsorption | |||
Maximum Cutting Thickness | 2mm | |||
Cutting Materials | White Paper, Kraft, Plastic Board, Fiberboard, etc | |||
Printing Speed | 60m2/h | |||
Plot/Cut Tool | HP45 Ink Box,Tungsten Steel Blade | |||
Precision | ≤0.01mm | |||
Communication Port | USB/RJ45 Ethernet; Shared Folder Print in LAN | |||
File Formats | HPGL(Compatible with Domestic and Interntional CAD Online) | |||
Control Panel | 9 Keys and LED Display(Chinese and English Switch) | |||
Motor/Driver | High Performance 3 Phrase Step-motor | |||
Supply Voltage | AC 220V/110V±10%, 50Hz | |||
Working Environment | Temperature:-30~50℃ or -22~122℉; Humidity: 10%--95% RH | |||
Paper Thickness | 150g-500g/m2 | |||
Application Areas | Garment, Shoes-Making, Bags, Furniture, Automobile Decoration, Box Cutting, etc |
Since its establishment, GEMEI has developed a series of cutting machines for clothing, bags, shoes and hats, and obtained a number of software copyright and patent certificates. Based on the profound understanding of China’s garment, luggage and footwear industry, GM series of cutting machine combines the essence of Chinese and foreign technologies, closely combines the advantages of the world's advanced technology and Chinese manufacturing industry, adopts a novel design different from the domestic traditional cutting machine, and fully experiences the design principle of "good at core, simple in shape". After the first continuous drum cutter came into being in the middle part of China , we successively developed the sample cutter for the luggage industry and continuous cutting garment sample cutter.
"The competition of enterprises is the competition of talents." GEMEI firmly grasps the trend that the world manufacturing
industry is transferring to the middle part of the world, and has established a research and development team composed of doctors and senior engineers and other high-quality talents,and insists that "innovation" is the eternal power of the development of GEMEI.
1. Q: Are you a manufacturer?
A: Yes, we are specializing in the r&d production for template cutter/inkjet cutter/pen writing cutter/cnc digital fabric cutter/graph plotter in this field for 10 years.
2. Q: How do you pack these products?
A: Usually packed in wooden case and can pack according to export standard or your requirement.
3. Q: Is it customizable?
A: Yes, We have basic sizes commonly applied in the field and can customize according to your requirements.
4.Q: After-sales service
A: Yes, professional after-sales team and 24-hour technical support by phone, email or skype
5.Q: What is your lead time?
A: Spot goods usually take 2-4 days, and customization takes 5-7 days
![]() |
